NP Pro Setup String Alignment

NP Pro Car Setup Package for String Alignment

The NP Pro Car Setup Package for String Alignment is a professional hub stand system designed for precise suspension geometry measurements in motorsport and performance workshop environments. This comprehensive vehicle setup solution uses the proven string alignment method to deliver accurate, repeatable measurements of toe, camber, caster, and ride height without the complexity or cost of laser-based systems.

Built for professional motorsport teams, race workshops, and serious enthusiasts, every component is CNC-machined from high-grade 6082 T6 aluminium and assembled in Lithuania under strict quality control standards.

Key Features & Benefits

• CNC-machined aluminium construction from 6082 T6 aluminium alloy ensures dimensional accuracy, corrosion resistance, and long-term durability even in demanding workshop environments
• Hub stand referencing system eliminates errors caused by wheel and tyre variations, providing more consistent measurements than traditional wheel-based alignment methods
• 35 mm height adjustment range accommodates different vehicle ride heights and allows precise leveling on uneven workshop floors
• Adjustable wheel offset from +12 mm to –50 mm provides flexibility for different hub and brake configurations across various vehicle types
• Interchangeable mounting plates allow adaptation to different bolt patterns and hub designs, with custom plates available for specialized applications
• Billet string offset add-ons enable precise string positioning for accurate toe and thrust angle measurements
• Digital dual axis angle reader provides instant, precise camber and caster readings with improved accuracy over analog gauges
• Complete transportation solution with purpose-built aluminium case and protective foam inserts keeps equipment organized and protected during transport to trackside locations

Complete Kit Contents

This professional setup package includes everything needed for comprehensive vehicle alignment:

• Custom NP Pro hub stands with leveling base plates and precision adjustment mechanisms
• Billet string offset add-ons for accurate string positioning and measurement
• Digital dual axis angle reader for precise camber and caster measurements
• Laser leveling tool to ensure accurate platform leveling and consistent measurement baseline
• Base leveling plate raisers for height adjustment and floor compensation
• Compact aluminium transportation box with custom foam inserts for secure storage and transport

Measurement Capabilities

The NP Pro Car Setup Package enables accurate measurement of all critical suspension geometry parameters:

• Toe – front and rear toe angles and individual wheel toe settings
• Camber – static camber angles for optimal tyre contact and handling balance
• Caster – steering axis inclination for stability and steering feel
• Ride height – precise corner weight and platform measurements

Materials & Construction

• 6082 T6 aluminium alloy provides an optimal balance of strength, low weight, and corrosion resistance with excellent machinability for precision components
• CNC machining ensures tight tolerances and consistent quality across all mechanical components
• Load transfer bearings allow smooth, precise adjustment without binding or play
• Anodized finish protects against corrosion and wear in professional workshop environments

Applications

• Motorsport vehicle setup and corner balancing for circuit racing, rally, and time attack
• Performance workshop alignment services for sports cars and modified vehicles
• Trackside setup operations where laser systems are impractical or unavailable
• Race team setup procedures requiring fast, repeatable measurements between sessions
• String alignment–based suspension tuning for accurate geometry verification
• Professional garage setup operations for high-performance and exotic vehicles

Compatibility

• Works with vehicles up to 380 mm brake disc diameter without modifications
• Custom mounting plates available on request for specialized vehicles, centerlock hubs, or unusual bolt patterns
• Suitable for most passenger cars, sports cars, and race cars with conventional hub mounting

Why String Alignment Is Important

String alignment is a proven, time-tested method used extensively in professional motorsport for its accuracy and reliability. Unlike optical or laser systems that can be affected by environmental conditions, string alignment provides direct, mechanical reference that is independent of electronic calibration drift or sensor limitations. Combined with hub stand referencing, the NP Pro system ensures measurements are taken from the true rotational center of each wheel, eliminating variables introduced by wheel runout, tyre irregularities, or rim damage. This approach delivers the repeatable precision essential for competitive motorsport setup work and high-performance applications where small geometry changes have significant effects on vehicle behaviour.

Manufacturing & Quality

All components are designed, CNC-machined, and assembled in Lithuania under controlled conditions. This European manufacturing approach ensures consistent quality, precise tolerances, and full traceability. Each unit undergoes quality inspection before shipping to verify dimensional accuracy and functional performance.

Technical Information

• Product type: Hub stand string alignment system
• Measurement method: String alignment with hub stand referencing
• Materials: 6082 T6 aluminium alloy, CNC-machined
• Height adjustment: 35 mm range
• Wheel offset adjustment: +12 mm to –50 mm
• Maximum brake disc diameter: 380 mm (without modifications)
• Intended use: Motorsport vehicle setup, professional workshops
• Manufacturing location: Lithuania (EU)
• Condition: New

Pricing & VAT

All prices are shown excluding VAT.

For bulk orders, motorsport team inquiries, or custom mounting plate requirements, please contact us.
